Full Wet Back Reverse Flame Chamber Structure 200 bhp 3 ton lpg fired hot water boiler

FOB Reference Price:Get Latest Price
$1,000.00 - $6,000.00 / Set | 1 Set/Sets (Min. Order)
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Type:
Natural Circulation
Usage:
Industrial
Structure:
Fire Tube
Pressure:
Low Pressure
Style:
Horizontal
Fuel:
Gas-fired
Place of Origin:
Henan, China
Brand Name:
Zhongding boiler
Model Number:
CWNS
Output:
HOT WATER
Dimension(L*W*H):
Depends
Weight:
5~50ton
Certification:
ISO
Capacity:
0.5-20t/h
Rated working pressure:
0.7
supply water temperature:
95 degree
Thermal efficiency:
92.4%--94.5%
water content:
depends
Design fuel:
Lng
Warranty:
18 Months
Model:
CWNS
Application:
Machinery Industry
After-sales Service Provided:
Engineers available to service machinery overseas
Supply Ability
Supply Ability:
100 Set/Sets per Month 3 ton wet back lpg fired hot water boiler
Packaging & Delivery
Packaging Details
Plywood case professional packaging transportation for this 3 ton wet back lpg fired hot water boiler
Port
Qingdao, Tianjin, Guangzhou, Shanghai etc
Lead Time :
Shipped in 25 days after payment
Video Description

Full Wet Back Reverse Flame Chamber Structure 200 bhp 3 ton lpg fired hot water boiler

Product Description

Product Description of 3 ton lpg fired hot water boiler:

This  Full Wet Back Reverse Flame Chamber Structure 200 bhp 3 ton lpg fired hot water boileris horizontal three-pass fire tube and fully wet back structure, suitable many fuels:oil, natural gas, lpg, diesel, light oil, waste oil, heavy oil and so on. The usage is drinking hot water, kitchen use, laundry, bathhouse, heating house, industrial production etc.

Fuel: Gas, oil, natural gas, lpg, diesel, light oil, waste oil, heavy oil and so on



Output: Hot water



Structure: Wet back, 3 phase return, Fire tube



Capacity: 2510-20900L



Pressure: Low pressure( 0.7-1.0 MW)



Thermal Effiency: 91-93%







Technical Parameter of 3 ton lpg fired hot water boiler:

 Parameter of wns oil gas fired bearing pressure hot water boiler



Model
WNS 1.05
WNS 1.4
WNS 1.75
WNS 2.1
WNS 2.8
WNS 4.2
WNS 5.6
WNS 7
Rated Power (MW)
1.05
1.4
1.75
2.1
2.8
4.2
5.6
7
Working Pressure (Mpa)
0.7
1
1
1
1
1
1
1
Supply Water Temperature (℃)
95
Return Water Temperature (℃)
70
Efficiency (%)
91-93
Water Capacity (L)
2510
3520
4000
4480
6630
13600
17200
20900
Outlet (mm)
80
100
100
100
125
150
200
200
Inlet (mm)
80
100
100
100
125
150
200
200
Drain Valve (mm)
50
50
50
50
65
65
65
65
Power Consumption (kw/h)
11
13.5
16
19
21
26
37
37
Chimney (mm)
350
350
480
480
480
600
700
700
Size
Length (mm)
3500
4000
4500
4800
5000
7850
8130
8600
Width (mm)
1850
1900
1950
2000
2000
2750
3570
3770
Height (mm)
2050
2200
2300
2500
2700
3460
3700
4150
Transport Weight (kg/h)
3400
4130
4800
6682
9200
12400
13400
15300
Fuel
Light Oil (kg/h)
98.5
131.3
164.2
197
262.7
394
525.4
656.7
LNG (Nm³/H)
119.4
159.2
198.9
238.7
318.3
477.5
636.6
795.8
CG(Nm³/H)
253.7
338.2
422.8
507.3
676.4
1014.6
1352.8
1691

Note:1. The hot value of LNG: 8500kcal/Nm³, hot value of light oil: 10300 kcal/Nm³, hot value of the city gas: 4000kcal/Nm³.

2. Data and pictures in sheet provide the reference only, the prduct takes real object as to allow, forgiving not to go

another circular such as the alteration beacause of remodel.

3. Prepare to make, reserve, and design of the boiler building, pleased conctact to confirm before relevant data.



Parameter of CWNS oil gas fired normal pressure hot water boiler



Model
CWNS 0.48
CWNS 0.58
CWNS 0.7
CWNS 1.05
CWNS 1.4
CWNS 1.75
CWNS 2.1
Rated Power (MW)
0.48
0.58
0.7
1.05
1.4
1.75
2.1
Working Pressure (Mpa)
Normal Pressure
Supply Water Temperature (℃)
85
Return Water Temperature (℃)
65
Efficiency (%)
90
Water Capacity (L)
630
900
1050
1560
2300
2700
3700
Outlet (mm)
65
80
80
100
100
125
125
Inlet (mm)
65
80
80
100
100
125
125
Drain Valve (mm)
40
40
50
50
50
50
50
Power Consumption (kw/h)
2.3
2.3
2.3
4
4.7
6.4
7.5
Chimney (mm)
250
250
250
300
350
460
500
Size
Length (mm)
2480
2670
2670
2930
3300
3530
3800
Width (mm)
1020
1120
1120
1360
1470
1580
1680
Height (mm)
1435
1485
1485
1760
1890
2010
2110
Size of base (mm)
2150*800
2350*900
2350*1000
2550*1000
2750*1100
3080*1200
3450*1200
Transport Weight (kg/h)
1550
1900
2100
2900
3750
3950
4950
Fuel
Light Oil (kg/h)
44.5
53.8
64.9
97.4
129.9
162.4
194.8
LNG (Nm³/H)
54
65.2
78.7
118
157.4
196.7
236
CG(Nm³/H)
114.7
138.6
167.2
250.8
334.4
418.1
501.7



This is just part of the product parameters, if you want to know more detailed parameters, please contact me.

Boilers Application of 3 ton lpg fired hot water boiler:

3 ton wet back lpg fired hot water boiler is mainly used in hotels, baths, small and medium enterprises, schools, textile, ect industries.



Get Price Now!

Packaging & Shipping

Packaging & Shipping of 3 ton lpg fired hot water boiler:

Our 3 ton wet back lpg fired hot water boiler have exported to many countries, such as Serbia, Nigeria,  Sri Lanka, Ethiopia, Turkey, Uzbekistan, Egypt, Lebanon and Pakistan etc.

Company Information

Company Information of 3 ton lpg fired hot water boiler:

Zhongding Boiler Co., Ltd is the national boiler manufacturing backbone enterprises, domestic boiler industry science and technology innovation-oriented enterprises, China's largest research and development of low circulating fluidized bed manufacturing base. Company has A-class boiler manufacturing license and the class-II and class-II pressure vessel manufacturing license, design level boiler installation license, the company passed the ISO9001 international quality system certification.ZhongDing boiler Co., Ltd was found the science and technology research and development of boiler manufacturing enterprise.

Certifications

Advantages

Advantage:

1. Reasonable internal structure: guarantee the excellent water circulation, and also reduce the fluid drag.

2. International known famous brand burner: make the fuel will be burned totally, save energy and meet the environmental requirements.

3. High automatic degree: English menu and LCD screen, programmed active, automatic purge, electronic auto-ignition, auto-combustion, flame out protection devices, all these make the operation is much simpler.

4. Intelligent control system: programmable control system and touch screen observe and control system and also has the ability of remote control function.

5. Intelligent adjustment of heating water and bathing water temperature: the boiler can work according to the setting time and setting temperature.
